Description
Introduction
This project introduces the basic Logic Gates: AND Gate, OR Gate, and NOT Gate. These gates are essential components in digital electronics, performing simple logical operations on binary inputs to produce specific outputs, and forming the foundation of digital computing systems.
System Components
- Input pins (2 for AND/OR, 1 for NOT)
- Output pin
- Diodes (for AND/OR gate implementation in some designs)
- Resistors (for current limiting and control)
- Transistors (used in NOT gate design)
Working Principle
-
- AND Gate:
- Outputs 1 only when both inputs are 1.
- Truth Table:
Input A Input B Output 0 0 0 0 1 0 1 0 0 1 1 1
- OR Gate:
- Outputs 1 when at least one input is 1.
- Truth Table:
Input A Input B Output 0 0 0 0 1 1 1 0 1 1 1 1
- NOT Gate:
- Outputs the opposite of the input (inverts it).
- Truth Table:
Input Output 0 1 1 0
- AND Gate:
Applications
- AND Gate: Used in control systems, decision-making circuits, and logical operations.
- OR Gate: Employed in circuits where any condition being true should trigger an action, like in alarm systems or security checks.
- NOT Gate: Essential in circuits that require inversion, such as flip-flops, inverters, and buffers in digital electronics.
